M4002-B Modern Design
Taxes included.
Choose your plan package
Preview Set: Dimensioned floor plans and external elevations in PDF format, for comparing layouts and preliminary site fit. Not for construction or approval submissions.
Working Set: Everything in the Preview Set, plus editable DWG/AutoCAD files for your chosen professional to adapt.
Site-specific drawings, engineering and approvals are not included. Revit files are priced separately on request.
Couldn't load pickup availability
Guaranteed Safe Checkout
Description
Split-Level Family Home
Key Specs
📐 252.2 m² 🛏️ 4 Bedrooms 🛁 2 Bathrooms 🚗 2 Car Garage 🏠 1 Storey
Description
This elegant split-level design offers a refined and slightly larger version of our “A” layout, with thoughtful updates that elevate both functionality and style. Designed to complement sloping or uneven sites, it provides spacious living areas, excellent natural flow, and modern family comfort.
The central open-plan kitchen, dining, and living area forms the heart of the home, connecting seamlessly to the outdoor alfresco for easy entertaining. The kitchen features a walk-in pantry and island bench, providing generous storage and preparation space.
The master suite includes a walk-in robe and ensuite, while three additional bedrooms with built-in robes offer space for family or guests. A large separate media room adds versatility — perfect as a home theatre, kids’ retreat, or secondary living area. A main bathroom and dedicated laundry complete the design, combining functionality with style.
✅ Highlights
-
Larger, refined version of the original “A” design
-
Split-level layout ideal for sloping blocks
-
Open-plan kitchen / dining / living area
-
Kitchen with island bench and walk-in pantry
-
Master suite with walk-in robe and ensuite
-
Three additional bedrooms with built-in robes
-
Large separate media room
-
Main bathroom and dedicated laundry
-
Outdoor alfresco for entertaining
Best Suited For
Families wanting a modern single-storey split-level home that combines practical living zones with open, airy spaces, ideal for sloping sites or those who love flexible, family-oriented design.
Floor Plan
Inclusions
Preview Set
Our Preview Set is for comparing layouts and discussing preliminary site fit, not for construction or an approval submission. Accurate dimensions of all rooms are provided along with external elevations which show details such as windows, doors, wall materials and roof style. These sets are priced low in order to allow for multiple sets to be purchased for comparison purposes. Set includes:
- Dimensioned floor plans in PDF format
- External elevations in PDF format
Working Set
Our working sets include all of the above plus the addition of CAD files. The Working Set adds editable DWG/AutoCAD files for your chosen professional to adapt the design. Purchasing these files does not include completed site-specific working drawings, structural engineering, energy assessments or approval submissions unless separately agreed. CAD files are provided to allow you the flexibility to chose your own designer to finalise the drawings or you may contact us for a quote to complete your working drawings for you. Set includes:
- Dimensioned Floor Plans
- All external elevations
- DWG/AutoCAD files
Can I use my own designer or builder?
Take the selected files to your own suitable professional, confirm software compatibility and agree who will complete site-specific drawings, engineering and any required approvals. AHDG custom drafting and site-specific approval drawings are offered only in Australia.
Can I build the plan more than once?
The published Copyright Agreement describes ordinary purchases as licensed for one build, with separate repeat-use provisions and an exception for eligible Builders Packages with CAD files. Check your exact package; editable files do not by themselves grant repeat-build, resale or redistribution rights. Read the Copyright Agreement.
What should I do after download?
Review the dimensions and elevations, confirm your permitted use, then arrange local site review and any necessary adaptation before construction. Compare PDF and CAD house plans.
