Split-Level Family Home

📐 208.4 m² 🛏️ 4 Bedrooms 🛁 2 Bathrooms 🚗 2 Car Garage 🏠 1 Storey


This versatile split-level home design is ideal for steep or sloping blocks, yet can be easily adapted for flat sites without losing its balance of functionality and flow. With its thoughtful layout, open spaces, and modern features, this design offers comfortable family living in any setting.

At the heart of the home is the open-plan kitchen, living, and dining area, designed for natural light and easy entertaining. The kitchen features a walk-in pantry and flows directly onto the outdoor alfresco, creating a seamless indoor–outdoor lifestyle.

The master suite includes a walk-in robe and ensuite, while three additional bedrooms with built-in robes provide ample space for family or guests. A large separate media room offers a quiet retreat or movie zone, and a dedicated study area adds functionality for work or homework.

A laundry area located within the garage maximises internal living space and ensures convenience for busy households.

This design combines flexibility, comfort, and practicality — perfect for families wanting a smart home that fits both sloping and level sites.


  • Split-level design ideal for steep or adaptable for flat blocks

  • Open-plan kitchen / living / dining area

  • Kitchen with walk-in pantry

  • Master suite with walk-in robe and ensuite

  • Three additional bedrooms with built-in robes

  • Large separate media room

  • Study area for work or study needs

  • Laundry area in garage for space efficiency

  • Outdoor alfresco for entertaining


Families looking for a flexible home design that works for both sloping and flat sites, offering modern living spaces, multiple zones, and an indoor–outdoor connection suited to the Australian lifestyle.


Floor Plan

All Our Full Working Drawings Sets include the following:

  • Floor plans
  • Site plan (if we have your site survey)
  • Elevations
  • Sections
  • Roof plan
  • Area legend
  • Door and Window schedule
  • 3D perspectives (black and white)



Additional services we can offer include*:

  • Wet area details
  • Construction details
  • Shadow diagrams
  • Colour floor plans, elevations and perspectives
  • Modifications to designs
  • Electrical Plan
  • Floor finishes plan
  • Slab layout plan

*Additional services will be charged at a rate of $132 per hour.

Due to the volatile nature of the Australian construction industry and lack of building materials at the moment, AHDG are unable to provide accurate building prices at this stage.

AHDG recommends purchasing our $99 Dimensioned Floor Plan + Elevations drawings and then contact local builders for pricing. This will be more economical than purchasing full working drawings. Please note, not all builders will be able to provide a quote with the $99 plans. They may require full working drawings.

Please contact us if you have any questions
