M4002-B

Split-Level Family Home

📐 252.2 m² 🛏️ 4 Bedrooms 🛁 2 Bathrooms 🚗 2 Car Garage 🏠 1 Storey

This elegant split-level design offers a refined and slightly larger version of our “A” layout, with thoughtful updates that elevate both functionality and style. Designed to complement sloping or uneven sites, it provides spacious living areas, excellent natural flow, and modern family comfort.

The central open-plan kitchen, dining, and living area forms the heart of the home, connecting seamlessly to the outdoor alfresco for easy entertaining. The kitchen features a walk-in pantry and island bench, providing generous storage and preparation space.

The master suite includes a walk-in robe and ensuite, while three additional bedrooms with built-in robes offer space for family or guests. A large separate media room adds versatility — perfect as a home theatre, kids’ retreat, or secondary living area. A main bathroom and dedicated laundry complete the design, combining functionality with style.

• Larger, refined version of the original “A” design

• Split-level layout ideal for sloping blocks

• Open-plan kitchen / dining / living area

• Kitchen with island bench and walk-in pantry

• Master suite with walk-in robe and ensuite

• Three additional bedrooms with built-in robes

• Large separate media room

• Main bathroom and dedicated laundry

• Outdoor alfresco for entertaining

Families wanting a modern single-storey split-level home that combines practical living zones with open, airy spaces, ideal for sloping sites or those who love flexible, family-oriented design.

Floor Plan

All Our Full Working Drawings Sets include the following:

• Floor plans
• Site plan (if we have your site survey)
• Elevations
• Sections
• Roof plan
• Area legend
• Door and Window schedule
• 3D perspectives (black and white)

Additional services we can offer include*:

• Wet area details
• Construction details
• Shadow diagrams
• Colour floor plans, elevations and perspectives
• Modifications to designs
• Electrical Plan
• Floor finishes plan
• Slab layout plan

*Additional services will be charged at a rate of $132 per hour.

Due to the volatile nature of the Australian construction industry and lack of building materials at the moment, AHDG are unable to provide accurate building prices at this stage.

AHDG recommends purchasing our $99 Dimensioned Floor Plan + Elevations drawings and then contact local builders for pricing. This will be more economical than purchasing full working drawings. Please note, not all builders will be able to provide a quote with the $99 plans. They may require full working drawings.
