M5003-B

Modern Two-Storey Family Home

📐 384.1 m² 🛏️ 5 Bedrooms 🛁 3.5 Bathrooms 🚗 2 Car Garage 🏠 2 Storey

This modern and efficient family home is a refined version of our M5003-A design, offering a more streamlined layout and cost-effective approach without sacrificing comfort or style. Designed for family living, it features spacious open-plan areas, multiple private retreats, and functional spaces ideal for both everyday life and entertaining.

At the heart of the home lies an open-plan kitchen, dining, and living zone, perfect for family gatherings and relaxed entertaining. The kitchen is stylish and practical, featuring a large island bench and a walk-in butler’s pantry, providing plenty of storage and preparation space.

Upstairs, the master suite offers a peaceful escape with a walk-in robe, ensuite, and private access to the front balcony, which can also be reached from the upstairs retreat/living area. Three additional bedrooms feature built-in robes, while a fourth bedroom with its own ensuite is ideal for guests or extended family. A study nook and main family bathroom complete the upper level, ensuring every family member has their own dedicated space.

Downstairs includes a powder room, laundry, and a large outdoor alfresco area with a built-in BBQ, creating the perfect setting for entertaining or relaxing outdoors.

• Streamlined version of the M5003-A design for better efficiency

• Open-plan kitchen / dining / living layout

• Kitchen with island bench and walk-in butler’s pantry

• Master suite with walk-in robe, ensuite, and balcony access

• Guest bedroom with built-in robe and private ensuite

• Three additional bedrooms with built-in robes

• Upstairs retreat / living room and study nook

• Main bathroom with full amenities

• Powder room and laundry downstairs

• Outdoor alfresco with built-in BBQ area

• Double garage with internal access

Families wanting a stylish and practical two-storey home that delivers space, functionality, and modern living without unnecessary extras. Perfect for growing families or multi-generational households looking for a balance between comfort, flexibility, and affordability.

Floor Plan
Ground Floor

First Floor

All Our Full Working Drawings Sets include the following:

• Floor plans
• Site plan (if we have your site survey)
• Elevations
• Sections
• Roof plan
• Area legend
• Door and Window schedule
• 3D perspectives (black and white)

Additional services we can offer include*:

• Wet area details
• Construction details
• Shadow diagrams
• Colour floor plans, elevations and perspectives
• Modifications to designs
• Electrical Plan
• Floor finishes plan
• Slab layout plan

*Additional services will be charged at a rate of $132 per hour.

Due to the volatile nature of the Australian construction industry and lack of building materials at the moment, AHDG are unable to provide accurate building prices at this stage.

AHDG recommends purchasing our $99 Dimensioned Floor Plan + Elevations drawings and then contact local builders for pricing. This will be more economical than purchasing full working drawings. Please note, not all builders will be able to provide a quote with the $99 plans. They may require full working drawings.
