M5006-B

Spacious Split-Level Family Home

📐 455.5 m² 🛏️ 5 Bedrooms 🛁 3.5 Bathrooms 🚗 2 Car Garage 🏠 2 Storey

This spacious and modern split-level family home is designed to deliver both style and functionality. Featuring five generous bedrooms, multiple living zones, and a seamless indoor–outdoor connection, this home is ideal for growing families or those who enjoy entertaining in comfort.

At the heart of the home is an open-plan kitchen, dining, and family area, filled with natural light and designed for easy living. The modern kitchen includes a walk-in butler’s pantry, ample bench space, and an inviting layout that makes cooking and entertaining effortless.

A large media room with built-in cabinetry and a dedicated study are located on their own split-level zone — providing quiet spaces for relaxation and productivity. Upstairs, the master bedroom offers a peaceful escape, featuring a walk-in robe, ensuite, and private balcony. Three additional bedrooms include walk-in robes, while a fourth features both a walk-in robe and ensuite, perfect for guests or extended family.

The upper floor also includes a family room and main bathroom, offering flexibility for kids or teenagers to have their own retreat. The lower level features a powder room, laundry, and large outdoor alfresco, creating an ideal space for entertaining or unwinding.

With clever zoning, this home balances privacy with open living, making it perfect for large families seeking both connection and space.

• Open-plan kitchen / dining / family area

• Stylish kitchen with walk-in butler’s pantry

• Split-level layout with study and media room on their own zone

• Master suite with walk-in robe, ensuite, and private balcony

• Guest bedroom with ensuite and walk-in robe

• Three additional bedrooms with walk-in robes

• Upstairs family room and main bathroom

• Downstairs powder room and laundry

• Large outdoor alfresco for entertaining

• Storage room in the garage

Families who want a large and versatile home with dedicated zones for work, relaxation, and entertainment. Perfect for those who value modern comfort, practical design, and luxurious touches — all within a functional family-friendly layout.

Floor Plan
Ground Floor

First Floor

All Our Full Working Drawings Sets include the following:

• Floor plans
• Site plan (if we have your site survey)
• Elevations
• Sections
• Roof plan
• Area legend
• Door and Window schedule
• 3D perspectives (black and white)

Additional services we can offer include*:

• Wet area details
• Construction details
• Shadow diagrams
• Colour floor plans, elevations and perspectives
• Modifications to designs
• Electrical Plan
• Floor finishes plan
• Slab layout plan

*Additional services will be charged at a rate of $132 per hour.

Due to the volatile nature of the Australian construction industry and lack of building materials at the moment, AHDG are unable to provide accurate building prices at this stage.

AHDG recommends purchasing our $99 Dimensioned Floor Plan + Elevations drawings and then contact local builders for pricing. This will be more economical than purchasing full working drawings. Please note, not all builders will be able to provide a quote with the $99 plans. They may require full working drawings.
