M5009-B

396.4 m²     🛏️ 5 Bedrooms     🛁 3.5 Bathrooms     🚗 2 Car Garage     ⬆️ 2 Storey

A refined evolution of our popular M5009-A design, this two-storey home offers the same flowing layout — with slightly smaller room dimensions and the removal of a few bonus zones for a more efficient footprint.

Enjoy the seamless blend of comfort, functionality, and style — perfect for growing families or those who love spacious living without unnecessary excess.

• 🏡 Open-plan kitchen, dining & living areas designed for natural flow

• 🍳 Generous kitchen with ample bench space and a walk-in butler’s pantry

• 🛏️ Large master suite featuring:

  • Expansive walk-in robe

  • Luxury ensuite with double vanity and shower

• 🛏️ Guest bedroom complete with private ensuite

• 🛏️ Three additional bedrooms each with walk-in robes

• 📺 Dedicated T.V. room on the first floor — ideal for family movie nights

• 🧺 Walk-in linen for practical storage

• 💻 Home office for remote work or study

• 🛁 Main family bathroom plus a downstairs powder room

• 🧼 Spacious laundry with easy access outdoors

• 🌤️ Alfresco entertaining area perfect for outdoor dining

• 🪜 Grand double-height entrance for a striking first impression

• 🧾 Laundry chute for ultimate convenience

This home delivers luxury living in a smarter, more efficient layout, retaining the sophistication of the original M5009-A while optimising every square metre. With open spaces, private zones, and thoughtful storage, it’s built for modern family life.

Floor Plan
Ground Floor

First Floor

All Our Full Working Drawings Sets include the following:

• Floor plans
• Site plan (if we have your site survey)
• Elevations
• Sections
• Roof plan
• Area legend
• Door and Window schedule
• 3D perspectives (black and white)

Additional services we can offer include*:

• Wet area details
• Construction details
• Shadow diagrams
• Colour floor plans, elevations and perspectives
• Modifications to designs
• Electrical Plan
• Floor finishes plan
• Slab layout plan

*Additional services will be charged at a rate of $132 per hour.

Due to the volatile nature of the Australian construction industry and lack of building materials at the moment, AHDG are unable to provide accurate building prices at this stage.

AHDG recommends purchasing our $99 Dimensioned Floor Plan + Elevations drawings and then contact local builders for pricing. This will be more economical than purchasing full working drawings. Please note, not all builders will be able to provide a quote with the $99 plans. They may require full working drawings.
