M5010-A
Australian House Design GroupKEY SPECS
303.39m2 5 Bedrooms 3 Bathrooms 2 Car Garage 2 Storey
DESCRIPTION
Modern Small Lot five bedroom family home spread over two levels.
-
Open plan kitchen/dining/living - dining room with two storey high ceilings
-
Walk in butlers pantry
-
Master bedroom with walk in robe and large ensuite
-
Three bedrooms with built in robes
-
Media room/fifth guest bedroom with built in cupboards
-
Kids retreat
-
Study nook
-
Main family bathroom
-
Front balcony with access from bedrooms 3 and 4
-
Downstairs bathroom
-
Laundry
-
Downstairs study nook
-
Large alfresco with built in BBQ
To modify this floor plan please contact us for a FREE quote. Click Here.
Floor Plan
Ground Floor
First Floor
All Our Full Working Drawings Sets include the following:
- Floor plans
- Site plan (if we have your site survey)
- Elevations
- Sections
- Roof plan
- Area legend
- Door and Window schedule
- 3D perspectives (black and white)
Additional services we can offer include*:
- Wet area details
- Construction details
- Shadow diagrams
- Colour floor plans, elevations and perspectives
- Modifications to designs
- Electrical Plan
- Floor finishes plan
- Slab layout plan
*Additional services will be charged at a rate of $132 per hour.
Due to the volatile nature of the Australian construction industry and lack of building materials at the moment, AHDG are unable to provide accurate building prices at this stage.
AHDG recommends purchasing our $99 Dimensioned Floor Plan + Elevations drawings and then contact local builders for pricing. This will be more economical than purchasing full working drawings. Please note, not all builders will be able to provide a quote with the $99 plans. They may require full working drawings.
